| Brand Name : | HONGHAI |
| Certification : | CE SGS ISO |
| Model Number : | PP-103 |
| Price : | 1000USD/SQM |
| Delivery Time : | 20 days |
| Payment Terms : | 50% tt & 50% balance before shipment |
| Supply Ability : | 2000sqm per month |
bumping video wall pantalla led stage backdrop p10 rgb led panel
Moving led screen structure for stage background design. The supporting structure can actually move in and out every few seconds or minutes, which makes the led panels pop in and out accordingly. Each combat box controls 8 to 10 led panels and programed to move in certain patterns. Contact me if you are interested.
For Youtube video links, pls visit:
https://youtu.be/CuamMXmC6nc
Contact : Tina Zhang
Mobile: +86 136 6632 7758
Whatsapp: +86 136 6632 7758
Viber: +86 136 6632 7758
Wechat: zt973787262
Skype: tina.zhang623
Advantage:
1.Low Carbon Dioxide Emission
2.Energy Saving and Eco-friendly
3.Stunning Visual Experience
4.High recall rate and attracting customers
| Parameters | available for all sizes and pixels of led cabinet | ||
| Pixels(mm) | 10mm | 16mm | 20mm |
| Physical Density (dot/m²) | 10000 | 3906 | 2500 |
| LED Light | DIP346 | ||
| Viewing Angle | Vertical 120° Horizontal 60° | ||
| Brightness (nits) | ≥6500 | ≥7500 | ≥5500 |
| Scanning Mode | 1/4 scanning | static | |
| Grey Level | 65536 | ||
| Refresh Rate(Hz) | ≥1000HZ | ||
| LED Module Size(mm) | 160×160x28.5 | 256×256x28.5 | 320×320x28.5 |
| Cabinet Size(mm) | 960×960x148.5 | 1024×1024x148.5 | 1280×960x148.5 |
| Cabinet Material | Metal Sheet | ||
| Cabinet Weight (kg) | 60 | 65 | 78 |
| Voltage | 220V | ||
| APC(W / m2) | 220 | 220 | 200 |
| MPC(W / m2) | 650 | 650 | 600 |
| Maintenance | Back Maintenance | ||
| Protective Level | Front : IP65,Back: IP54 | ||
| Working Temperature/Humidity | Temperature:-20℃~ 50℃ Humidity:10~90%RH | ||
| Storage Temperature/Humidity | Temperature:-40℃~ 60℃ Humidity:10~90%RH | ||
| Service Life(h) | ≥50000 | ||
| Quality Standard | CCC,CE | ||
| Full Screen Thickness | 1150mm | ||
| Track Flexibility | 200mm | ||
| Stop Time | Adjustable | ||
| Popping Type | 3-18 ways, optional | ||
| Material | LED Module + Metal Sheet Box | ||
Structure with Moving Motions
Certificate:
Factory View:
Honghai Photoelectric Group Co., ltd.
China's leading creative billboard manufacturer, Exclusive supplier
of tri-vision billboard for Shanghai 2010 World Expo, CNC control
throughout the whole production line, 260 workers, 20000 square
meters non-dust workshop, 20 years experience, ISO, CE,
For latest innovation, see Youtube Video Channel: https://www.youtube.com/channel/UCVfK6qWAXHfOSL55j8Wch_Q
Constant Innovation and Pursuit of Pefection.
|
|
